Linear MegaCode ACT-22A 3-Channel Key Ring Transmitter (minimum 10)


SKU: linear-act-22a

Sold in multiples of 10 only. The Model ACT-22A 3-Channel Key Ring Transmitter is designed for use with Linear’s access control products. The Model ACT-22A is a three-channel device. Pressing the transmitter’s left or right front button sends channel one or two. Pressing both buttons sends channel three. Lithium batteries with a five-year service life are included and the transmitter is supplied with a quick-disconnect key ring. A unique 10-second time-out feature prevents the system from being shut down by a single transmitter transmitting continuously.

The transmitter is MegaCode format, which means each transmitter is factory preprogrammed with one of over 1,000,000 codes, virtually eliminating the possibility of code duplication. Because the receiver ”learns” each specific code, no unauthorized person can gain access to the system by reprogramming a transmitter.


Compatible with all Linear access receivers and controllers
Supplied with quick-disconnect key ring
Minimum order quantity 10 transmitters
Power: Two 1616 batteries
Codes: 1,000,000+ (MegaCode format)
RF frequency: 318 MHz
Dimensions: 1.25” W x 2.25” H x 0.48” D
